BioHub® 3D Cubic Foldable Plastic Bin

BioHub® 3D Cubic Foldable Plastic Bin are designed for storage and transport of small to medium volume media, buffers and intermediate solutions. When in use, it can be folded and stacked, which can effectively improve the space utilization rate of the clean factory area.


Inquiry Download
Features Specifications Contact us

Features of BioHub® 3D Cubic Foldable Plastic Bin

  • Polypropylene (PP) material, with good chemical compatibility, strong acid resistance and stable performance in various inorganic solvent environments.

  • Good mechanical properties. It can be folded and stacked to improve the space utilization of the clean factory area.

  • Volume range: 250L, 500L, 1000L.

  • The material is clean and uniform, and the inner wall is smooth, which will not cause damage to the soft bag body.

  • The operating temperature range is -20°C ~60°C (cannot be sterilized by high temperature steam).


Specifications of BioHub® 3D Cubic Foldable Plastic Bin

3D Storage Bags and Matching Supporting Bins

Part numberMatch typeSpecificationLine 1Line 2Line 3
BBPC-0100-S001

BioLinkplastic bin

100 L50cm ID3/8"*OD5/8"
Platinum cured silicone tubing +
female MPC connector		50cm ID3/8"*OD5/8"
Platinum cured silicone tubing +
male MPC connector		30 cm ID1/4"*OD7/16"
Platinum cured silicone tubing +
needleless sampling valve
BBPC-0100-S002BioLink
plastic bin		100 L

50cm

ID3/8"*OD5/8"

Thermoplastic

tubing + plug

50cm ID3/8"*OD5/8"
Thermoplastic tubing + plug		30 cm ID1/4"*OD7/16"
Thermoplastic tubing +
needleless sampling valve
BBPC-0250-S001BioLink
plastic bin		250 L

50cm

ID3/8"*OD5/8"

Platinum cured

silicone tubing +

female MPC

connector

50cm ID3/8"*OD5/8"
Platinum cured silicone tubing +
male MPC connector		30 cm ID1/4"*OD7/16"
Platinum cured silicone tubing +
needleless sampling valve
BBPC-0250-S002BioLink
plastic bin		250 L

50cm

ID3/8"*OD5/8"

Thermoplastic

tubing + plug

50cm ID3/8"*OD5/8"
Thermoplastic tubing + plug

30 cm

ID1/4"*OD7/16"

Thermoplastic

tubing +

needleless sampling valve
BBPC-1000-S001BioLink
plastic bin		1000 L

50 cm

ID3/4"*OD1"

Platinum cured

silicone tubing +

TC50

50 cm

ID3/4"*OD1"

Platinum cured

silicone tubing +

TC50

30 cm ID1/4"*OD7/16"
Platinum cured silicone tubing +
needleless sampling valve
*Customizable upon request. Contact BioLink experts in your location for your needs.

Product Specifications


Cubic Foldable Plastic Bins 250 LCubic Foldable Plastic Bins 1000 L
Part numberARCABIN0250L001ARCABIN1000L001
Capacity - Internal/external264L/0.41CBM1060L/1.51CBM
Matching bags100L, 250L500L, 1000L
Outer dimensions - unfolded, with cover809*609*833 mm1155*1155*1132 mm
Outer dimensions - unfolded, without cover800*600*810 mm1145*1145*1110 mm
Inner dimensions740*540*660 mm1065*1045*940 mm
Outer dimensions - height after folded403 mm467 mm
Footprint0.5 m²1.33m²
Weight20 kg89 kg
Maximum dynamic capacity700 kg (2 layers)2,977 kg (2 layers)
Maximum static capacity1,750 kg (5 layers)7,442 kg (5 layers)
Material
PP
Operating temperature range
-20 ℃ to + 60 ℃

Carts for Cubic Foldable Plastic Bins

Part numberMatching Cubic
Foldable Plastic Bins		MaterialConfigurationWheelsCart Dimensions (mm)Cart
Weight
ACART0250L001
ACART1000L001		250 L
1000 L		SS 304LRegular

4

brake


wheels		600*800*200
1,161*1,161*243		28 kg
35 kg
ACART0250L002
ACART1000L002		250 L
1000 L		SS 304LWith load cell,
With 4–20 mA
output		4 brake
      wheels		1,048*600*820 (instrument height 1,010)
1,061*1,360*425 (instrument height 1,090)		35 kg
45 kg
